YG 60 Gloss Meter

Products >> Bliss NDT Instruments >> YG 60 Gloss Meter

TH-160 Split Segment Code Screen Leeb Hardness Tester

FEATURES:

Small – Only 80 grams weight, size as small as name card
Accurate – Passed metrological certification
Fast – Single measure time less than 1S
Long – Continuous measure 10000 times after recharge
Auto Calibration – no need for manual calibration, measure immediately after power on, intelligent
Calibration base – Anti-pollution, calibration at any time, to ensure long-term accuracy.

Optional Probe Selection

Modle	YG60 SE	YG60 Pro	YG60 Max
Calibration	Automatic
Measure Angle	600
Parameter	Gloss (GU)
Aperture	23 x 7 mm
Measure range	0-200 GU	0-1000 GU	0-1200 GU
Stability	1 GU	0-100:0.1GU;>100:1GU
Repeatability	1	0.2 / 0.2%	0.1 / 0.1%
Measure time	Less than 1s
Battery	Rechargeable, 5000 times continuous tests	Rechargeable, 10000 times continuous tests	Rechargeable, 12000 times continuous tests
Display	IPS full color screen, 135 x 240, 1.14 inch
Interface	USB	USB, Bluetooth
Working temperature	0400C
Humidity	<85%, with no condensation
Accessories	USB cable, Straps, Manual, Calibration base, Cleaning cloth
Weight	80g	116g
Size	84mm x 70mm x 17mm
